ID # 25781948

Bauma Light ST324

Videos
Call for Price
Overview

ST324: Small Fixed Compact

This fixed frame hydraulic tree spade is ideal for smaller skidsteers. The ST324 Small Fixed Compact tree spade features three blades to give you the digging and root ball compacting action necessary for cleaner and more viable transplants.

Specifications
Model
ST324
Year
2023
Sale Type
New
Manufacturer
Bauma Light
3PH
3000 lbs Min.
Backhoe
4000 lbs
Slides
Steel
Weight
1100
Telehandler
4000 lbs
Wheel Loader
4000 lbs Min.
Opening (Width)
20"
Root Ball Depth
23"
Hydraulic Flow
5-20 (GPM)
Number Of Blades
3
Standard Mount
Universal skidsteer
Blade Thickness
1/4" Mild Steel
Tracked Skidsteer
4500 lbs
Wheeled Skidsteer
5000 lbs
Blade Truncation
Semi
Root Ball Diameter
24"
Tree Size (Hardwood)
1.5"
Blade Angle (Degrees)
25°
Tree Size (Evergreen)
3"
features


https://baumalight.com/stump-grinder/img/features/local-support.jpg SOLD BY EQUIPMENT DEALERS

All Baumalight products are sold through our network of equipment dealers. For you, this means better product support, after-sales service, maintenance and product warranty from your local, trusted dealership

Bauma Light ST324 D001539 - Optional Stabilizer for Various Root Ball Sizes

Can be field installed. Adjustments at 6", 8", and 10".

Part number is D001539
Spade stabilizers for root ball sizing per piece (4 hours extra labor if field installed)

Bauma Light ST324 D001542 - Optional Outrigger for Skidsteer

Ships with weld-on plate.

Part number is D001542
Out Rigger set for back end of skid steer (with weld-on bracket)

Bauma Light ST324 Anti Slip

Non slip step pads for easy entry.

Bauma Light ST324 JIC Fittings

Secure hydraulic conectios and easy servicing.

Bauma Light ST324 Sleeved Hoses

All hoses are sleeved for operator and hose protection.

Bauma Light ST324 Powder Coat Finish

Heavy-duty construction and a durable powder-coated finish.

Bauma Light ST324 Lifting Eye

Lifting eyes for easy storage and transport.

Bauma Light ST324 Semi Truncated Blades

The most utilitarian blade style that provides a narrower bottom cut for the root ball. These blades also provide greater soil penetration in clay with better compression to to hold sandier soils.

Bauma Light ST324 Cylinders Push for Maximum Efficiency



Bauma Light ST324 Universal Skidsteer Adaptor



Bauma Light ST324 Bolt in Tractor Loader Adaptor

Note: Not included in Price of Spade

Bauma Light ST324 Wide Range of Control Options

Increase the efficiency of your tree spade operation with the Controls line of remotes from Baumalight.
