Model |
1386 |
1186 |
|
Due to continuing improvements in the design and manufacture of Unverferth products, all specifications contained herein are subject to change without notice. |
|
Undercarriage |
1250/50R32 (201A8 LI) Singles |
1050/50x32 (178A8 LI) Singles |
|
Capacity- bushels (mt) |
1330 (33,78) |
1125 (28,58) |
|
Unloading Speed - bu/mn (mt/min) |
625 (15,88) |
625 (15,88) |
|
Auger Diameter (cm) |
Turbo 22" - 20" (55,88 - 50,8) |
Turbo 22" - 20" (55,88 - 50,8) |
|
Min. Tractor H.P. Requirements |
200+ |
200+ |
|
Appx. Empty Weight - lbs. (kg) |
18,740 (8500) |
16,720 (7584) |
|
Appx. Empty Tongue Weight -lbs. (kg) |
|
|
|
Appx. Loaded Tongue Weight - lbs.(kg) |
5,200 (2359) |
4,700 (2132) |
|
Overall Width (m) |
15' 2" (4,62) |
14' 8" (4,47) |
|
Overall Length (m) |
31' 3" (9,53) |
30' 10" (9,40) |
|
Hitch to Center of Tire (m) |
18' 6" (5,64) |
18' 6" (5,64) |
|
Hopper Length (m) |
25' 9" (7,85) |
22' 1" (6,73) |
|
Hopper Width (m) |
13' 1/2" (3,98) |
11' 1" (3,63) |
|
Hitch Height (cm) |
19 1/2" (49,53) |
18" (45,72) |
|
Transport Height - with Tarp (m) |
13' 1" (3,99) |
12' 11" (3,94) |
|
Load Side Hopper Height (m) |
11' 8" (3,56) |
11' 7" (3,53) |
|
Auger Side Hopper Height (m) |
12' 8" (3,86) |
12' 6" (3,81) |
|
Height to Bottom of Downspout Unfolded - Adj. (m) |
13' 1" - 11' 1"
(3,99 - 3,38) |
13' 1" - 11' 1"
(3,99 - 3,38) |
|
Height to Top of Auger Unfolded - Adj. (m) |
18' - 16'
(5,49 - 4,88) |
18' - 16'
(5,49 - 4,88) |
|
Height to Bottom of Downspout in Transport Position (m) |
4' 3" (1,30) |
4' 3" (1,30) |
|
Height to Top of Auger in Transport Position(m) |
8' 8" (2,64) |
8' 8" (2,64) |
|
Auger Side Reach - Adj. (m) |
8' 3" (2,51) |
8' 3" (2,51) |
|
Auger Front Reach (cm) |
3' 5" - 2' 3"
(104,14 - 68,58) |
3' 5" - 2' 3"
(104,14 - 68,58) |
|
Underframe Ground Clearance (cm) |
14 1/2" (36,83) |
14" (35,56) |
|
Axle Ground Clearance (cm) |
25" (63,5) |
22" (55,88) |
|
Center of Tire to Center of Tire (m) |
11' 2 1/2" (3,42) |
11' 2 1/2" (3,42) |
|
Turret Downspout Left Reach (cm) |
4 1/2" (11,43) |
4 1/2" (11,43) |
|
Turret Downspout Right Reach (cm) |
22" (55,88) |
22" (55,88) |
|
Spout Diameter (cm) |
22" (55,88) |
22" (55,88) |
|
Hub/Spindle Sizes |
12-Bolt & 6" (15,24) |
10-Bolt & 4 1/2" (11,43) |
|
Back Slope |
30° |
30° |
|
Front Slope |
32° |
32° |
|
Loaded Ground Pressure P.S.I. (bar) |
|
42"x148" Equalizer Tracks (kgf/cm²) |
11.00 (,77) |
- |
|
36"x148" Tracks (kgf/cm²) |
12.80 (,90) |
- |
|
42"x131" Equalizer Tracks (kgf/cm²) |
12.80 (,90) |
10.00 (,70) |
|
36"x131" Tracks (kgf/cm²) |
- |
12.00 (,84) |
|
1250/50x32 Singles - 201A8 LI (kgf/cm²) |
22.00 (1,55) |
17.00 (1,20) |
|
1250/50x32 Singles - 188A8 LI (kgf/cm²) |
- |
17.00 (1,20) |
|
1050/50x32 Singles (kgf/cm²) |
- |
20.28 (1,43) |
|
35.5x32 Singles - 193A8 LI (kgf/cm²) |
- |
25.20 (1,77) | |
