Vermeer TG7000E TUB GRINDER

Specifications

Model	TG7000E TUB GRINDER	Category Name	Equipment	Year	2025
Sale Type	New	Manufacturer	Vermeer	Odometer	km
Price	Contact for price CAD

Description

As your stationary operation looks to electric-power, Vermeer is your partner for the equipment expertise you need. The TG7000E tub grinder is powered by two electric motors providing a combined 1000 hp (746 kW) to the mill. With the option to configure either a soft-start or VFD starter panel - along with Vermeer features like the duplex drum design and continuous undermill discharge conveyor system - the TG7000E has the flexibility and features you need for productive processing.

DIMENSIONS

Maximum_Reach_of_Loader

29.5 ft (9 m)

Maximum_Width_(Transport)

11.9 ft (3.6 m)

Maximum_Height_(Transport)

11.3 ft (3.4 m)

Maximum_Length_-_Transport

48.5 ft (14.8 m)

Weight_-_Engine_Option_One

70800 lbs (32114.3 kg)

Rear_Mount_Pad_Weight_(Operation)

50250 lbs (22793 kg)

Front_Mount_Pad_Weight_(Operation)

49450 lbs (22430.1 kg)

Maximum_Length_-_Conveyor_Unfolded

68.8 ft (21 m)

Maximum_Height_-_Cab_in_Operating_Position

18.7 ft (5.7 m)

OPERATIONAL

Depth_of_Tub

4.7 ft (1.4 m)

Loader_Reach

29.5 ft (9 m)

Tip_Diameter

29 in (73.7 cm)

Drum_Diameter

22.5 in (57.2 cm)

Grapple_Weight

1450 lbs (657.7 kg)

Loading_Height

11.3 ft (3.4 m)

Wall_Thickness

.3 in (.6 cm)

Millbox_Opening

27" x 69" (68.9 cm x 175.3 cm)

Drum_Cutting_Width

65.3 in (165.9 cm)

Tub_Cover_Positions

Transport and Operate with Hydraulic Lock. Transport also has mechanical lock

Tub_Table_Thickness

.5 in (1.3 cm)

Idler_Roller_Diameter

12 in (30.5 cm)

Tub_Cover_Description

Hydraulically activated

Inside_Diameter_of_Tub

10 ft (3 m)

Magnetic_Drive_Roller_Diameter

13.8 in (35.1 cm)

Standard_Drive_Roller_Diameter

13.8 in (35.1 cm)

Thrown_Object_Restraint_System

Standard

Loader_Lift_Capacity_at_Full_Reach

4000 lbs (1814.4 kg)

Loader_Lift_Capacity_at_10_'_(3.05_m)

12000 lbs (5443.1 kg)

Inside_Flare_Diameter_-_At_Base_of_Tub

10.3 ft (3.1 m)

Inside_Flare_Diameter_-_At_Tub_Opening

13 ft (4 m)

FEATURES & OPTIONS

Features

Engine Information Yes
Machine Information Yes
Motor Information Yes
Rotor Deflector

Options

Air Cleaner - Pleated Primary (4) and Secondary (4) with precleaners (2) and electric restriction indicator (2)
Air Compressor Brand - Mi-T-M
Air to Boil Temperature - 122 deg
Air to Boil Temperature - 142 deg
Alternator - 24 Volt, 100 Amp
Alternator - 24 Volt, 75 Amp
Axle Type - Tri-Axle Air Ride
Capacity - 20000 lbs (9071.8 kg)
Clutch Engagement - Push Button
Clutch Engagement - Push button
Clutch Type - Hydraulic Operated Wet Clutch
Coolant Capacity (Engine and Radiator) - 34 gal (128.7 L)
Coolant Capacity (Engine and Radiator) - 42 gal (159 L)
Cooling Medium - Liquid
Drive Shaft - Custom Spicer
Engine - 11.7 hp (8.7 kW) Honda
Extended Warranty - Optional
Fan - 60" (152.4 cm) Dia, Fixed Pitch, Hyd Reverse Option
Fan - 60" (152.4 cm) diameter, fixed pitch, hydraulic reverse
Fuel Tank Capacity - 500 gal (1892.7 L)
Fuel Type - Ultra Low Sulfur Diesel
Fuel Type - Ultra low sulfur diesel or low sulfur diesel
Gross Horsepower (Maximum) - 950 hp (708.4 kw)
Ground Clearance - Option One - 13.5 in (34.3 cm)
Ground Clearance - Option Two - 10 in (25.4 cm)
Make and Model - C27 Tier 4 Final
Make and Model - Caterpillar C27 Tier 2/Stage II
Max Fuel Consumption - 45.7 gph (173 lph)
Max Fuel Consumption - 47.5 gph (179.8 lph)
Maximum Air Flow - 29 cfm (.8 cmm)
Maximum Pressure - 175 psi (12.1 bar)
Number of Cylinders - 12
Oil Filter - Spin-on (2)
Oil Volume with Filter - 72 qt (68.1 L)
Oil Volume with Filter - 76 qt (71.9 L)
Preventative Maintenance - Optional
Recommended Oil - 15W40
Recommended Oil - CAT DEO-ULS, API CJ-4, API CK-4, or ECF-3 10W-30 / 15W-40
Screens - Optional
Sound Power - Sound Power (LwA) = 120.0 dB(A) Equivalent Continuous A-Weighted Sound Pressure at Operator's Ear (Laeq) = 100.0 dB(A) - Main Control Station Equivalent Continuous A-Weighted Sound Pressure at Operator's Ear (Laeq) = 77.0 dB(A) - Loader Cab
Sound Power - Sound power (LwA) = 118.4 dB(A) Equivalent continuous A-weighted sound pressure at operator's ear (Laeq) = 97.2 dB(A) - main control station Equivalent continuous A-weighted sound pressure at operator's ear (Laeq) = 74.4 dB(A) - loader cab
Special Paint - Optional
Special Tools Group - Optional
Tank capacity - 30 gal (113.6 L)
Tires - Option One - 425/65R22.5 Super Singles
Tires - Option Two - 255/70R22.5 duals
Torque (Max) - 3202 ft-lb (4341.3 Nm)
Torque (Max) - 3212 ft-lb (4354.9 Nm)
U - Joints - Permanently Lubricated 10C (qty 2)
Wheels - Option One - 22.5" x 12.25" Hub Piloted Aluminum
Wheels - Option Two - 22.5" x 8.25" Hub Piloted Steel
