Vermeer RANCHER 6640 BALER |
|||||||||||||||||
|
|||||||||||||||||
|
Specifications
|
|||||||||||||||||
|
Description
|
|||||||||||||||||
|
DIMENSIONS
|
|||||||||||||||||
|
Tires
31 x 13.5-15
Height
111 in (281.9 cm)
Length_standard
160 in (406.4 cm)
Length_with_net
181 in (459.7 cm)
Length_with_ramp
171 in (434.3 cm)
Weight_(Fully_Optioned)
5220 lbs (2367.8 kg)
Width_with_standard_tires
95 in (241.3 cm)
|
|||||||||||||||||
|
DRIVETRAIN
|
|||||||||||||||||
|
Driveline
540 rpm, standard lube, friction clutch
Torque_protection_pickup
Radial pin clutch
Bearing_and_Sprocket_Configuration
Round drive shafts and bearings — hex shaft on drum
|
|||||||||||||||||
|
OPERATIONAL
|
|||||||||||||||||
|
Display
7 in (17.8 cm) color touch screen
Belt_Type
Endless belts
Flotation
Gauge wheels 7.10-16 HD semi-pneumatic with spring assist
Bale_Width
47 in (119.4 cm)
Tooth_Bars
10
Pickup_Lift
Hydraulic
Pickup_type
Camless wide
Type_of_Lace
No laces
Bale_Diameter
36 in - 72 in (91.4 cm - 182.9 cm)
Teeth_spacing
3-1/16 in (7.8 cm)
Width_of_Belt
6.8 in (17.3 cm)
Stripper_bands
Poly
Number_of_Belts
6
Number_of_Teeth
(40) double rubber-mounted
Density_readings
Digital gauge
Drum_roller_size
12 in (30.5 cm)
Field_Statistics
50 fields with names
Drive_Roller_Size
5.5 in (14 cm)
Idler_roller_size
3.5 in (8.9 cm), 4.8 in (12.1 cm)
Start_Roller_Size
4.5 in (11.4 cm)
Control_system_type
Atlas Pro™ control system
Maximum_bale_weight
1300 lbs (589.7 kg)
Net_tension_control
via control system
Width_tooth_to_tooth
43.5 in (110.5 cm)
Length_of_belt_(long)
492 in (1249.7 cm)
Length_of_belt_(short)
482 in (1224.3 cm)
PTO_horsepower_minimum
50 hp (37.3 kw)
Width_on_outside_flair
58 in (147.3 cm)
Bale_density_adjustments
Standard through control system monitor
Field_statistics_download
USB
PTO_horsepower_recommended
70 hp (52.2 kw)
|
|||||||||||||||||
|
LITERATURE
|
|||||||||||||||||
|
Literature
|
|||||||||||||||||
