ID # 14167760

Schulte FLX-1510 Flex Arm

  • Schulte FLX 1510 Flex Arm
  • Schulte FLX 1510 Flex Arm
  • Schulte FLX 1510 Flex Arm
  • Schulte FLX 1510 Flex Arm
  • Schulte FLX 1510 Flex Arm
  • Schulte FLX 1510 Flex Arm
  • Schulte FLX 1510 Flex Arm
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
  • Video Button Maxresdefault
In Stock
Blow Out Price - Call dealer for details!
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

 Features
  • Increase operator safety, comfort and performance with the revolutionary Schulte Flex-Arm.
  • The Schulte Flex-Arm allows the operator to travel on the road while his Schulte 10’ or 15’ rotary cutter cuts the ditch slope.
  • The tractor does not have to ride on the ditch slope so rollovers are very low risk. As an added bonus, wear & tear on the tractor is greatly reduced.
  • Operator comfort is greatly increased. Operators who have had a chance to use the Schulte FLEX-ARM say comfort & safety are the best features.
  • Visibility is improved. The operator is placed in a better position to view obstacles before they reach the rotary cutter.
  • The FLEX-ARM and Schulte cutter can be used in wet conditions, which could make cutting more difficult if the tractor had to ride on the slope.
  • Because of the unique way in which the FLEX-ARM is attached to the rotary cutter, it can be easily backed up to cut around approaches and other obstacles
Specs
  • New heavy duty 11L x 15, 12 ply tires with a load capacity of 4000 lbs.
  • Cut directly in-line with the tractor or at any offset distance up to 122” (10.16ft)
  • Large 2-1/2” castor pivot shaft
  • 6000 lb capacity 6 bolt hubs
  • Spring steel tension bushings and induction hardened pins at major pivot points
  • Minimum of 3 hydraulic circuits required to operate the FLEX ARM with a 15’ or 10’ mower
  • If independent wing lift is required on 15’ mower then 4 hydraulic circuits or optional _selector valve kit is required
  • Heavy duty 3-1/2 X 36 welded hydraulic cylinder
  • Weight of the FLX-1510 is 2557 lbs
  • Safety lighting kit
  • Bolt-in replaceable axles
  • Easily detached from the rotary cutter by disconnecting the hitch and the stabilizer strut
  • Continuous power rating of 200HP at 1000 RPM
  • Accommodates 540 or 1000 RPM power delivery from the tractor
  • Optional 6 port selector valve kit for independent wing action or limited tractor hyd. outlets
  • Transport widths:
    • Arm & rotary cutter. 70” to the left of the tractor and 52” to the right for a total of 121”
    • Arm alone. 70” to the left of the tractor and 47” to the right for a total of 117”
    • Arm & rotary cutter with stop block installed on the transport lock bar. 55” to the left of the tractor and 66” to the right. In this configuration the arm is 19” off center. The stop block can be installed when working on narrow roads to improve clearance for oncoming traffic.




Specifications
Model
FLX-1510 Flex Arm
Category Name
Agriculture
Year
2023
Sale Type
Used
Manufacturer
Schulte
Cutting Width
126'' (3.20 m)
Cutting Height
1.5 to 17.5'' (38 to 144 mm)
Overall Width
139'' (3.53 m)
Overall Length
192'' (4.88 m)
Cutting Capacity
4'' material (102 mm)
Blade Overlap
6.5'' (165mm)
Videos Documents
