New Holland E70D Midi Excavators
Photo Gallery
Call for Price
Overview
Specifications
features
description
driveline
dimensions
capacities
performance
literature
Documents
New Holland Construction enters the midi excavator market with its first model. The midi excavator category combines powerful performance and versatility in a compact design. These machines come with a wide set of features as standard equipment and have mechanical, technological and productivity-related optional equipment. Several segments can benefit from having this new size of excavator such as landscaping, amenity work, agriculture, horticulture, nurseries, vineyards, estate management, water and sewer, municipal projects, and general contracting. Choose this size of midi excavator for a variety of projects from urban settings to outdoor field projects. |
E70DOperators are going to find a machine uniquely built for them and their needs with the powerful performance within E70D's compact frame. This excavator is meticulously crafted to excel in confined spaces where larger machines fall short. Ideal for small-to-medium-sized construction companies, landscapers, municipalities, and farmers, the E70D can handle a variety of tasks with ease — from digging and grading to material handling. |
AN EXCAVATOR LINE WITH MORE POWER AND CAPACITY Model
E70D
Category Name
Equipment
Year
2026
Sale Type
New
Manufacturer
New Holland
Max Power (2300 Rpm)
60.2 HP (44.3 kW)
Max Dump Height- Std/Long Arm
175.2 in (4450 mm) / 180.7 in (4590 mm)
Max Digging Depth - Std/Long Arm
160.2 in (4070 mm) / 168.1 in (4270 mm)
Features
Impressive specifications and versatile design are intrinsic to the E70D making it a standout model. Weighing in at 16,072 lbs (7290 kg), it strikes the perfect balance between strength and agility. It delivers a dig depth of up to 168.1 inches (4269 mm) and a dump height of 180 inches (4572 mm) and is engineered for peak performance in a variety of conditions. Sporting a distinctive monoboom design that ensures superior maneuverability, the machine allows operators to navigate tight spaces and challenging jobsites with ease. |
|
|
GREAT SET OF SPECIFICATIONS
ATTACHMENTS AND OPTIONS
REMOTE TRACKING AND DIAGNOSTICS Operating Weight Lb
16072
Number Of Arm Options
2
Standard Arm Length Ft/in
6 ft 3 in
Engine Model
V2607-CR-T
Rated Speed Rpm
2300
Displacement In³
160
Track Shoe Width In
17.7
Zero Tailswing
Dozer Blade Type
Straight
Ground Clearance In
14.2
Max Transport Height Ft/in
8 ft 10 in
Dig Depth - Mono Boom Ft/in
13 ft 4 in
Track Length On Ground Ft/in
7 ft 1 in
Dump Height - Mono Boom Ft/in
14 ft 7 in
Width Over Fixed Tracks Ft/in
6 ft 11 in
Undercarriage Width Ft/in
6 ft 11 in
Vertical Wall - Mono Boom Ft/in
12 ft 1 in
Transport Length Mono Boom Ft/in
20 ft 1 in
Ground Level Reach - Mono Boom Ft/in
21 ft 8 in
Tailswing Radius Ft/in
3 ft 5 in
Fuel Tank Gallon (US)
22.5
Hydraulic Tank Gallon (US)
15.8
Arm Tearout Lbf
6519
Bucket Breakout Lbf
10903
Number Of Main Pumps
2
Travel Speed - Low Mph
1.3
Travel Speed - High Mph
2.6
Main Pump - Flow Gallon (US)/min
44.3
Literature
| Name | Link |
| E70D Midi Excavator Specifications | Download |
