The New Holland Construction Small Articulated Loader (SAL) line introduces a groundbreaking solution for operators, excelling in smaller tasks with exceptional lifting capability. Offering the perfect blend of commodity and convenience, these machines provide operators with enhanced visibility, spacious cabs, and a range of attachments for seamless multitasking on any surface.
ML15
The new small articulated loader (SAL) line from New Holland equips operators with the compact power to get more done. The effective combination of strength, versatility, and the light footprint makes the ML15 exceptional for smaller tasks on any surface. A force to be reckoned with, the impressive lifting capacity handles loads with ease. Discover the various features that seek to enhance stability and safety in the ML15.
With a narrow width of 43.3 inches (1100 mm) and overall height of 87.8 inches (2230 mm) the ML15 model is suitable for landscapers focused on clearing sidewalks or fenced-in areas with limited space. Machine length without a bucket comes in at 107.0 inches (2718 mm), length with bucket at 133.4 inches (3389 mm).
The small articulated loader series provides unmatched agility to maneuver in tight spaces. Perfect for various landscaping and light construction jobs, these machines are just the right size for snow and debris removal on sidewalks and in backyards, hauling landscaping materials, removing fallen trees or for working on jobsites with sensitive surfaces. Don't be misled when reading 'small' in all this talk regarding New Holland's small articulated loaders; the compact size still provides powerful lifting capabilities.
STRENGTH AND STABILITY
Jobsites and tasks requiring heavy machinery power delivered through a compact package can turn to New Holland's small articulated loaders.The ML15 model showcases a lifting capacity of 3,086 lbs (1400 kg), tipping load capacity of 3,307 lbs (1500 kg) and lifting height of 81.4 inches (2067 mm).
The 26 HP (19.4 kW) machine boasts a 3,362 lbs (1525 kg) operating weight, allowing for minimal ground disturbance when turning or hauling on soft ground like turf. The ML15 comes fitted with an open cab, ROPS/FOPS safety roof and a 55.9 inch (1205 mm) wheelbase. The low center of gravity allows for stable operations, contributing to seamless and precise performance.
POWER POSSESSING FEATURES
Key features of the ML15 include a hydrostatic 4-wheel drive and a CII mechanical attachment coupler with a huge selection of attachments allowing the ML15 to tackle any job you need done.
Unlike other small articulated loaders in its class, the ML15 features articulation and oscillation to provide ultimate stability, helping to prevent the loss and shifting of material during operation.
A RANGE OF POSSIBILITY
Model ML15's lift allows operators to load and unload materials from large trucks and the reach provides more flexibility in dumping, leveling and grading tasks. The 26 HP (19.4 kW) machine excels at dumping and loading on the job site by providing 81.4 inches (2067 mm) of lifting height and 53.5 inches (1360 mm) of dumping height
COMMODITY AND CONVENIENCE
WHEN COMPACT MEETS CONVENIENT
STRENGTH AND STABILITY
POWER POSSESSING FEATURES
A RANGE OF POSSIBILITY
ML15_Spec Sheet_NHC7130238303.pdf
