MacDon A Series

  • MacDon A Series
  • Video Button Maxresdefault
Videos
Call for Price
 Get a Quote  Get Financed  Value a Trade  Contact Us  Book a Demo   Get Directions  Print
Overview

A Series Auger Headers

A clean cut, smooth flow, and excellent conditioning, that’s what you get from MacDon A Series Auger Headers. Like all MacDon harvesting machines, the A Series is designed to perform in the toughest conditions while providing exceptional durability.
Specifications
Model
A Series
Category Name
Agriculture
Sale Type
New
Manufacturer
MacDon
features

TRIED, TESTED, AND TRUE PERFORMANCE

From the heavy-duty cutterbar, to the cast housing of the dual Wobble Boxes and rugged internal components of the knife drive system, the A Series is a commercial quality machine that high-acreage producers rely on to deliver proven harvesting performance and reliability.
a series auger header specifications
Size 4.9 M (16') 5.5 M (18')
Weight 2295 kg (5058 lbs) 2381 kg (5248 lbs)
Sickle: Type / Drive / Speed / Stroke / Guards / Sickle Sections Double knife / Hydraulic, dual MacDon Wobble Boxes / Variable 1450 to 1900 spm / 76 mm (3") / Pointed DHT (double heat-treated) / 76 mm (3") over-serrated, bolt-on
Reel: Type / Drive / Speed (Optional Sprockets) / Fingers* 6 bat, oval closed bats with end caps, sectioned bar with greaseable ball bearings / Hydraulic, motor to enclosed gearbox / Variable from cab 51 to 85 rpm / Steel
Conveyor (Auger): Type / Drive / Speed (Optional Sprockets) / Delivery Width 508 mm (20”) undershot, center-feed auger over replaceable, high-density polyethylene auger pans, rubber feed fingers / Hydraulic, direct-mounted motor / Variable from cab 230 to 320 rpm / 2430 mm (95.7”)
Conditioner: Type / Roll Length / Outside Dimension / Drive / Speed Non-contact, steel N-bar, intermeshing crimping rolls, header-mounted rolls and forming shields / 2590 mm (102”) / 233 mm (9.17”) / Hydraulic motor to enclosed gearbox / Variable 601 to 790 rpm
*Max Speeds Will Be Dependent Upon Windrower Model
windrower to header compatibility
  A40D A0DX D65 D1X D1XL R85 R1 R2
M1170   ✓   ✓ ✓   ✓*
M1170NT       ✓ ✓Up to 10.6 m (35')
M1240   ✓   ✓ ✓ ✓4.9 m (16') ✓4 m (13') ✓
M155/M155E4 ✓   ✓     ✓ ✓*
M205 ✓   ✓     ✓4.9 m (16')   ✓**
* Double Windrow Attachment Not Available
** R2 Grass Seed Special Header Is Not Compatible With M205
literature
Name Link
A Series Brochure Download
